KDS Kylin Goggles

Thank you for choosing Kylin Vision headset Goggles, which comes with a 5.8G full band reception.

Supply Voltage for Kylin Vision is 4.2V- 8.4V, and 1S lipo battery is suggested.

Key Features：

Wireless receiving display image;

5 inch Screen;

5.8G receiver;

Full-band 5645M~5945M,automatic research and scan to match the transmitter;

Lipo battery 1S 2000mAH, USB charge;

Working Voltage：4.2V;

Resolution: 800X480(WVGA);

Brightness: 300cd/m2(adjustable)

Contrast: adjustable

Saturability: adjustable

Sensitivity:-90dBm±1dBm

Antenna Interface：External thread（Internal thread internal pin antenna）1 x RP-SMA, 50 Ohm;

Video format:  NSTC/PAL;

Audio:  adjustable;

Charging Voltage：DC 5V/ 1A;

Dimension: 169*169*109mm;

Weight: 385g;

Consumption: 300 mA
