Tamiya 58579 1/10 CC-01 LandFreeder 4WD RC Pickup Truck Kit

Tamiya 1/10 CC-01 LandFreeder 4WD RC Pickup Truck Kit

The LandFreeder is inspired by the look of a '80s pick-up truck. The body of this truck newly designed and it's made of polycarbonate material for tough durability. The truck is mated to the all-terrain CC-01 chassis for fun and realistic trail running.

The CC-01 chassis features independent front suspension and a rear solid axle for true scale R/C driving. It’s an ideal platform for R/C enthusiasts who enjoy trail running at their favorite outdoor spot.

Features

Chassis: CC-01, plastic tub construction
Drive: Four wheel drive, shaft driven
Motor: 540 electric motor
Electronic Speed Control: TEU-104BK with reverse
Shocks: Oil-filled, black plastic construction
Gearbox: Front and rear sealed gearbox
Differentials: Planetary gear, rear differential may be locked during assembly
Transmission: Single speed
Body: Clear untrimmed polycarbonate
Tires: Semi-pneumatic all-terrain, rubber construction 1.1" (29mm) wide, 3.5" (90mm) diameter
Wheels: Five spoke chrome plated plastic, 1" (26mm) wide, 1.9" (48mm) diameter
Bumper: Front, plastic construction, black in color
Suspension: Front, long stroke double wishbone Rear, four link rigid
Camber Tie Rods: Fixed non-adjustable
Caster: Adjustable, caster/toe-in refers to the angle of the front suspension when viewed from the side of the car in relation to the chassis
Steering: Bell-crank type with servo saver and adjustable linkage

Includes

Tamiya LandFreeder kit with oil-filled shocks, 540 motor, ESC, clear body, tires, wheels, shock oil, 16 tooth pinion gear, spur gear, instructions.

Needed to Complete

• 2 Channel Radio and Receiver
• Standard Size Servo for steering
• 7.2V NiMH Battery with standard Tamiya connector
• Charger for Battery
• Paint and Building equipment

Specs

VEHICLE-
Length: 17.5" (445mm)
Width: 7.7" (195mm)
Height: 8.5" (215mm)
Weight: 53.3oz (1510g)
Wheelbase: 9.5" (242mm)

BODY-
Length: 15.75" (400mm)
Width: 6.6" (167mm)
Height: 4.25" (108mm)
