MiniGRS Flybarless System Specification
●Operating voltage range: DC 3.5~8.4V
●Operating current consumption: <100mA @ 4.8V
●Rotational detection rate: ±300°/sec
●Rudder yaw detection rate: ±600°/sec
●Sensor resolution: 12 BIT
●Swashplate Support: 120° CCPM Swashplate
●Mode Support: T-REX250, T-REX300, T-REX450, T-REX470, T-REX500
●Receiver Support: ALIGN A10(A.BUS), Futaba S-FHSS, DSM2/DSMX
●Operating temperature: -20℃ ~ 65℃
●Operating humidity: 0% ~ 95%
●Comply with RoHS restrictions
●Size: 37.6x22.4x13mm
Balance Charger RCC-3SX Specification
●Input Voltage: AC 100V~240V(50/60Hz)
●Output Voltage: 2cell DC 7.4V / 3cell DC 11.1V
●Supported Battery Type: Li-polymer / Li-ion
●Charging Method: CC/CV
●Charging Current: 2A
●Size: 123x74.3x32mm
●Weight: 260g
Battery Specification
●Output: 11.1V 1300mAh 14.4Wh(3S1P)
●Supports 5C charging
●Dimension: 74x36.5x21mm
●Weight: 115g
●14AWG heat-resistant silicone rubber wire. Heat resistance: 200 ° C / Current withstand: 50A
