| Approx. Flying Duration: | 6 minutes |
|---|
| Assembly Time: | 5-7 Hours |
|---|
| CG (Center of Gravity): | 2-3/16 in (55mm) back from leading edge at wing root |
|---|
| Control Throw (Ailerons): | Low: 3/8 in (10mm) up/down; High: 1/2 in (12mm) up/down) |
|---|
| Control Throw (Elevator): | Low: 3/8 in (10mm) up/down; High: 1/2 in (12mm) up/down) |
|---|
| Control Throw (Rudder): | Low: 9/16 in (15mm) left/right; High: 13/16 in (20mm) left/right |
|---|
| Experience Level: | Intermediate |
|---|
| Flying Weight: | 30.4-33.6 oz (860-950 g) |
|---|
| Fuel Type: | Electric |
|---|
| Is Assembly Required: | Yes |
|---|
| Main Wing Tube Length: | 332mm |
|---|
| Main Wing Tube OD: | 5mm |
|---|
| Motor Size: | 450- to 480-size motor |
|---|
| Overall Length: | 30.4 in (775mm) |
|---|
| Plane Type: | Scale Civilian |
|---|
| Power Plant Size: | 450-480 Electric |
|---|
| Prop Size: | 10 x 5 Electric Propeller |
|---|
| Radio: | 4-channel minimum radio system |
|---|
| Recommended Environment: | Outdoor |
|---|
| Recommended Motor Battery: | 11.1V 3S 1800-2200mAh LiPo |
|---|
| Servos: | (2) sub-micro and (3) super sub-micro servos |
|---|
| Speed Control: | 30-Amp Brushless |
|---|
| Spinner Size: | 1-3/4 in (45mm) |
|---|
| Trim Scheme Colors: | UltraCote Pearl Blue (U845), Silver (U881), True Red (U866), Bright Yellow (U872) |
|---|
| Wing Area: | 235 sq. in. (15.2 sq. dm.) |
|---|
| Wingspan: | 35.4 in (900mm) |
|---|
