K10476A Brushless ESC Cooler Plate / Heat Sink

K10476A Brushless ESC Cooler Plate

Be the first to review this product

Manufacturer: Align

Availability: 4 in stock

SKU: K10476A

Old price: $9.20

Price: $5.80

Qty:

Ship to

*

*

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Product:

Step 1:Cut open the existing heat shrink tubing. If there are heatsinks on both sides of the ESC, first remove the heatsink on the flat heat dissipation plate, then remove the dust insulators on both sides of the ESC	Step 2:Heat transfer compound at the back side of the cooler plate already,Using a hobby knife as shown in the photo, spread the thermal grease evenly on the back of the heatsink

Step 3:Attach the heatsink to the flat heat dissipation plate	Step 4:To avoid short circuit of the ESC, care must be taken to position the heatsink exactly as shown in the diagram

Step 5:Slide the included heat shrink tube on to both sides	Step 6:Apply heat using heat gun or lighter to shrink the heat shrink tubing

Package:

Instructions:	Specification:
●Apply for RCE-BL60G/70G/75G/100G Brushless ESC. ●High efficiency large surface area heatsink for ESC, to improve motor and BEC maximum output current by 15%.	●ESC cooler plate x 1(48x31x16mm) ●Heat shrink tube x 2(Φ28x10mm) ●Weight:15.4g
