Hobbywing 30901065 XRotor Micro BLHeli 20A 3-4s 4 IN 1

• 4IN1 ESC w/BEC - Super Small & Light architecture
• 32-Bit ARM Processor w/ 48MHz
• Premium MOSFETs (Toshiba MOSFETs)
• Ceramic capacitors
• built-in drive ICs, 3-ounce copper
• Ultra high efficiency & rapid response - 6 layers of PCBs and other quality components guarantees less heat.
• Motor Block-up Protection
• Splash-proof

Oneshot125, Oneshot42 & Multishot Modes Ready

• Supports regular throttle signals (with the frequency of up to 621Hz),
  Oneshot125 (125-250μs) high-speed throttle signals (with the real-time frequency of up to 3.8KHz),  also Oneshot42 (42-81μs) and Multishot (2-25μs) super
  High-speed throttle signals. All this makes communication between FC and ESC more agile, throttle linearity smoother, and throttle response extremely faster

DEO Technology/Active Freewheeling

The DEO (Driving Efficiency Optimization) technology implemented in the ESC has multiple advantages:

• Active braking. When reducing the throttle amount, the motor will decelerate very quickly. This feature enables pilots to more easily perform all maneuvers like sharp turns, altitude changes, and sudden braking.
• Higher driving efficiency, longer flight time.
• Lower ESC temperature and a more reliable operation

Model................... 4in1 Micro

SKU....................  30901065
Application............ FPVs with 130-280mm Diagonal Wheelbase
LiPo Power input.... 3S-4S
Cont.Current.......... 20Ax4
Burst Current......... 25Ax4
BEC Output............ 5.3V/12V, 3A
Input wires............ 16AWG-130mm* (Red/Black)

Output Wire

Black-20AWG-100mm*3
Black-20AWG-95mm*3
Black-20AWG-85mm*3

Connectors...............no (raw wires) (In/Out)

Weight ...........24.5g

Size................54*36*7mm

Throttle Calibration..... Supported

ESC Programming........ Supported

DEO.......................... Supported

OneShot Mode............ Supported

Timing Not Supported

Motor Rotation Not Supported
