Hobbywing 80060022 SkyWalker Brushless 40Amp V2 ESC

Skywalker 40amp V2 econo air ESC 2-3S

Features

• Safety arming feature: Regardless the throttle stick position, the motor will not spin after battery connected.
• Throttle calibration funtion: Throttle range can be calibrated to be compatible with different transmitters.
• User programmable.
• Multiple program methods supported: transmitter stick, LED Program Card. Very easy to program the ESC at home or at the flying field.
• Compatible with Lipo and NiMH battery.
• Timing can be changed to be suitable for different brushless motors.
• Full protection: Low voltage cutoff protection / Over-heat protection / Throttle signal loss protection.

Specification

• p/n: 80060022
• Model: 40A V2
• Cont.Current: 40A
• Peak.Current: 60A
• Input Vol (Lipo): 3-4S
• BEC Output: 5V @ 5A (Switch-mode)
• Size (mm): 60x25x8
• Weight (g): 36
• Wires input: 14AWG-100mm
• Wires output: 16AWG-75mm
• Output connectors: 3.5 Gold Connectors (Female)
• Programming: Stick / LED program box
• Firmware update: N

Max motor limit:

v1: 210000rpm for 2 Poles BLM*, 70000rpm for 6 poles BLM*, 35000rpm for 12 poles BLM*

*BLM = BrushLess Motor
