HML80M13 800MX Brushless Motor(720KV/4530)

HML80M13 800MX Brushless Motor(720KV/4530)
Manufacturer: Align
Availability: 1 low stock
SKU: HML80M13
$349.00
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Product:
Product:
Drawing:
Specification Drawing:
Wiring Schematic Drawing:
Instructions:Specification:
●To meet the power and torque requirements of enthusiasts, the high output 800MX motor was born in Align’s R&D lab. With dramatic increase in torque and power output, capable of 2660 watts continuous power output and 4400 watts of burst power!
●800MX features high efficiency, superior power, excellent torque, low current draw and low temperature,it’s capable of maintaining consistent torque and head speed through continuous F3C maneuvers..
●Due to the 800MX’s high efficiency and low current draw, the standard equipment 120A electronic speed controller are sufficient to experience the power of this motor, and extend battery longevity.
●800MX motor incorporates radial fan in its end bell, creating powerful airflow to dissipate heat. Tweaks to motor design and reduction in weight not only contributes to dramatic power increase, the high efficiency cooling system enables cooler operating temperature during and after flights when compared to motor of previous generation.
●The 800MX motor armature are dynamically balanced to eliminate typical imbalance found in other outrunner motors.
●Maintenance free、high torque、high efficiency、stable, and low noise.
●High-speed ball bearings, powerful magnetic outrunner rotor.
●Suitable For Other 700 Models F3C.

For more detailed information, please refer to the Power Tip

800MX Brushless Motor usage notices

Instruction for setting the ICE2 HV 120 governor mode with 800MX

●Input Voltage:12S
●Max Continuous Current: 120A/200A(2sec)
●Max Output Power: 2660W/4400W(2sec)
●KV Value: 720KV
●Stator Dimension:4530
●Stator Arms: 12
●Magnet Poles: 10
●Dimension: Spindle 6x56.7x94.5mm
●Weight: 515g
Accessories:
●Socket screw(M4x10)x4
●Washer(Φ4xΦ8x1)X4
●5.5mm gilt terminal x 3
