HEBPCU01 PCU Power Control Unit Set

● Suitable for M480L / M690L.
● Must with APS-M. Can be used with OSD+FPV Video Transmitter, G2/G3 Gimbal, Retractable Landing Gears, External Status LED.
● Intelligent Power Control Unit (PCU) acts as the centre piece for power and signal management, distribution, and control. With a single battery, the system distributes power to motor, flight control, gimbal, retract, downlink system, etc. In addition, it integrates all signals between APS-M, G2/G3 gimbal, OSD, and the data downlink system. It also controls gimbal’s panoramic photo mode, fix point photo mode, and retract system. The system will automatic power off in 3 minutes after aircraft has landed and remain stationary. The PCU system provides the most safe and reliable management of all power and signals on the Multicopter.

● Input Voltage：13.2V~25.2V(4S~6S Li-Po)
● Operating Frequency：500KHz
● Operating Temperature：-5°C~45°C
● Dimension：62x35x26mm
● Weight: Approx. 94.56g

●PCU Power Control Unit Set x 1
●M480 Multi-purpose Battery Cover x 1
●Multicopter 4MM Gold Connector (Male) x 2 (φ4.9x20mm)
●Multicopter 3.5MM Female Terminal x 2 (φ2xφ14.4x12.5mm)
●Socket Screw - Nylok x 2 (M2.5x6mm)
