Align H70G012XX 102T M1 Helical Autorotation Tail Drive Gear Set

H70G012XX 102T M1 Helical Autorotation Tail Drive Gear Set

Be the first to review this product

Manufacturer: Align

Availability: Out of stock

SKU: H70G012XX

$50.70

Qty:

Product:

Package:

T-REX 700 Tail Drive Gear Ratio With Main Rotor Speed Table:

Main Blades	Tail Blade	RPM approx.	Tail Drive Gear	Front Drive Gear	Drive Gear Ratio
700	106	2150 ~ 2200 RPM	102T	23T	8.46/1/4.43
700	106	2000 ~ 2150 RPM	104T	22T	8.46/1/4.73
700	106	< 2000 RPM	105T	20T	8.46/1/5.25
For your safety, please pay attention to the above 2200 RPM, incorrect excess 2200 RPM may result in damage to the helicopter or injury the porperty of others.

Instruction:

Specification:

●Use for T-REX 700X/700E/760X/800E.
●Brand new low drive gear ratio with high strength and wear resistance,effectively reduce the tail vibration during speedy rotation keeping well tail lock performance and power output to prevent unexpected structure issue.
●Gear Ratio 1:4.43

●102T M1 Autorotation tail drive gear set x 1
●23T M1 Front drive gear assembly set x 1
