Align H70097A 700Metal Tail Pitch Assembly

Instruction:

●Utilizes dual point attachment design for zero play and higher precision control feel.
●Constructed with CNC aluminum alloy, with precision ball bearing at moving points, improving structure rigidity and smoothness, allowing rudder control to be more precise and smooth.
●Suitable for all 700 class machines.
●6061-T6 Aluminum alloy material and CNC processed.

Specification:

●I-shaped Arm � 1
●Mount Link � 1
●Mount � 1
●Collar � 1(Φ8�Φ9.4�4mm)
●Bearing holder � 1
●Bearing MR128ZZ � 2(Φ8xΦ12x3.5mm)
●Linkage ball C(M2x4) � 1(Φ5x9mm)
●Tail control arm � 1(37.5�10.7�4mm)
●Bearing F682XZZ � 6(Φ2.5�Φ7.1Φ2.6mm)
●Socket button head screw � 1(M3x5mm)
●Socket button head screw � 6(M2.5x5mm)
●Socket button head screw � 1(M2.5x6mm)
