Great value and performance in this economy range of brushless speed controllers.
Features:
- Auto detect the cells and type of batteries, and set the cutting-off voltage accordingly, 6V/9V for 2 and 3 cell lipo, and 0.8V/cell for Ni-Mh/NiCd batteries.
- Safe start, it will not start up when the throttle not at the zero position.
- Over-temperature protection: The ESC will stop working when surface temperature is over 110?.
- Lost signal protection: The ESC will stop when control signal is lost for over 1 second.
| Specifications: |
| Weight | 8g including leads |
| Size | 23.5 x 15.7 x 6.1mm |
| Const. Current | 10A |
| Max Current | 15A (10s) |
| BEC | 2A at 5V |
| PWM | 8kHz |
| Input | 4-12 NiMh/NiCad 2-3 Lipo |
