DS Power DS-S006M Sub Micro 9g servo MG (fits Draco, replacement for SA332)

Manufacturer: DS Power
Availability: 8 in stock
SKU: DSPower DS-S006M
$29.50
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Product Description

DS-S006M is a high torque, digital mini servo that performs. An excellent urgrade for the standard mini servo found in many 1/16 scale vehicles.

Similar size as a standard 9g servo.



Operating Voltage:                 4.8V-6V DC
No Load Speed:                     <0.13sec/60° at 4.8V(Ref.)
                                               <0.11sec/60° at 6.0V(STD.)
Stall Current:                          <700mA at 4.8V (Ref.)
                                               <800mA at 6.0V (STD.)
Stall Torque:                           >1.3kgf.cm at 4.8V (Ref.)
                                               >1.5kgf.cm at 6.0V (STD.)
Pulse Width Range:               500-2500uS
Operating Travel Angle:          90° ±10°
Mechanical Limit Angle:          210°
Weight:                                   13.5g ±0.5g inc wires.
Case Material:                         ABS
Gear Set Material:                   Metal gears
Motor Type:                             Coreless motor
Size:                                        27.3 × 12 × 23mm
Length of Connector cable:     JR 250±5mm (exposed without plug)
No load current:                       150mA at 4.8V and 170mA at 6.0V

Specifications

Scale
1/16
Brand
DS Power
Product Code
DS-S006M
Weight
0.02kg
