Captron HC3D HeliCommand 3D

HeliCommand 3D

Applications

These systems are designed to make it easier for the hobby modeller to control model helicopters. The HeliCommand 3A, 3D and Rigid are not suitable for use in built-up areas, in the vicinity of buildings or above roofs.
The device is also not intended for use in manned aircraft and / or for military applications. Contraventions of this rule are rigorously prohibited, constitute an infringement of licence, and will be pursued by legal action.The HeliCommand Profi is designed for use in particularly high-quality model helicopters and industrial machines, as well as for commercial applications such as filming, photography and surveying etc.

This variant includes the same features as the HeliCommand 3A, plus:

• Attitude stabilisation when inverted
• Excellent as a supplementary switchable flying aid, or as an �emergency button� during brief 3D manoeuvres.

The PC connection set is required in order to use these supplementary features.

It is possible to upgrade the basic HeliCommand to the HeliCommand 3D version at any time by upgrading the system software; this work must be carried out by the manufacturer�s Service Department.

Specification:
Operating voltage: 4.8 - 6 Volts (4 - 5 NC)
Current drain: 55 mA
Weight, incl. cables: 33 g
Dimensions: 55 x 35 x 22.5 mm
