Align HERT1001 T10 Transmitter Set (Multi Rotor only)

Be the first to review this product

Manufacturer: Align

Availability: Out of stock

SKU: HERT1001

$179.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Product:

Product:

Product:

Product:

Product:

Focus Shot1(T10 Transmitter)	Focus Shot2(AR18i Receiver)		Focus Shot3(Ni-MH chargeable battery AA)

Focus Shot4(Phone Screen Bracket/Monitor Mount)	Focus Shot5(AR18i Signal Wire/Micro USB)		Focus Shot6(User Guidance And Precautions)

Package:

ALIGN T10 Transmitter mode2 to mode1:

T10 Specification:		AR18i Specification:
●Channel: 10 channels ●Model Type: Quadcopter ●RF Range: 2.4055 ~ 2.475 GHz ●RF: <20dBm ●System Mode: 2.4G system AFHDS 2A ●Power Input: 4.2V ~ 6.0V ●Display: 73x39mm, LCD Backlight touch screen ●Transmit Distance: In open space without interference <1000M ●Antenna Length: 26mm(Dual Antenna) ●Weight: 410g(not incloude battery) ●Dimension: 179x81x161mm ●Certificate: CE0678, FCC, NCC(CCAJ16LP2890T5)		●Channel: 18 channels ●RX Sensitivity: -105dBm ●RF Range: 2.4055 ~ 2.475 GHz ●System Mode: 2.4G system AFHDS 2A ●Power: 4.0 ~ 6.5V DC ●Transmit Distance: In open space without interference <1000M ●Weight: 14.9g ●Dimension: 27x26.2x15mm ●Certificate: CE0678, FCC, NCC(CCAJ16LP3030T2)
Instructions:		Accessories:
●AFHDS2A(Automatic Frequency Hopping Digital System Second Generation) features with superior protection against interference, low power consumption, and high sensitivity receiver. ●Capacitive touch screen design makes setup much intuitive and simple. ●Equipped with 4 switches, 2 knobs and 2 buttons for multi-functionality setup. ●Support Mode 1, Mode 2, Mode 3, Mode 4 stick mode. ●Independent identification ID enhance the system stability of proactive anti-interference. ●High efficiency Omni-directional gain antenna maintaining a strong reliable connection. ●Optional mobile phone holder available for FPV screen viewing. ●Feature with update function. ●Feature with stick trim function.		●T10 Transmitter x 1 ●Phone Screen Bracket x 1 ●Monitor Mount x 1 ●AR18i Receiver x 1 ●AR18i Signal Wire x 1 ●1.5V Ni-MH chargeable battery(AA size) x 4 ●Micro USB x 1 ●User Guidance x 1 ●Precautions x 1
